BIM-enabled PEX (cross-linked polyethylene) piping system designed for potable water supply in residential and commercial buildings. Includes fully parametric Revit family with configurable pipe diameters (1/2" to 2"), fittings, and manifold connections. Compliant with ASTM F876/F877 and NSF/ANSI 61 for potable water safety. Model includes accurate LOD 300 geometry, flow rate data, pressure ratings, and material properties for integration into plumbing and MEP BIM workflows.
Manufacturer:
Category:
File Format:
RTE
test.rte
File Size:
4.11 MB
Properties:
Version
v1
Released
Sep 22, 2026
Downloads
1
Version 1 Details:
File Name:
test.rte
File Extension:
RTE
File Size:
4.11 MB
Release Date:
Sep 22, 2026
Changelog:
Initial version
Product created
Sep 22, 2026
Product approved
Sep 22, 2026
